| Turntable section | |||||
| Type | Belt-driven analogue turntable system | Belt-driven semi-automatic turntable system with USB interface | Direct drive manual turntable system | Premium belt-driven HiFi turntable | Direct drive fully manual turntable system |
| Drive | Belt drive | Belt drive with auto stop mechanism | Quartz driven upper-torque direct drive | External drive belt on the acrylic platter | Quartz driven upper-torque direct drive with precision rotation |
| Motor | DC motor | DC motor | 16pole, 3phase, brushless DC motor | Decentralised DC motor | 16pole, 3phase, brushless DC motor |
| Turntable speeds | 2 speeds (33 1/3, 45) | 3 speeds (33 1/3, 45, 78 rpm) | 3 speeds, fully manual (33 1/3, 45, 78 rpm) | 2 speeds (33 1/3, 45) | 3 speeds, fully manual (33 1/3, 45, 78 rpm) |
| Starting torque | 4500 g/cm | 4500 g/cm | |||
| Start-up time / rpm change | less than 0.2 sec. | less than 0.3 sec. | |||
| Wow and flutter | 0.2% WRMS | 0.2% WRMS | 0.01% WRMS | < 0.2% WRMS | 0.01% WRMS |
| S/N ratio | >60 dB or higher | >60 dB or higher | More than 55dB (DIN-B) | >45dB or higher | More than 60dB (DIN-B) |
| Brake system | electronic brake | electronic brake | |||
| Turntable platter | |||||
| Material | aluminium die-cast | aluminium die-cast with deadening rubber | aluminium die-cast with deadening rubber | acrylic | aluminium die-cast |
| Diameter | 300 mm | 300 mm | 332 mm | 300 mm | 305 mm |
| Weight | About 0.5 kg | About 1 kg | About 1.8 kg (including rubber mat) | About 1.7 kg | About 2.1 kg |
| Tonearm section | |||||
| Type | Static balanced straight tonearm | Static balanced straight tonearm | Universal static balanced S-shaped | Straight carbon tonearm | Static balanced S-shaped |
| Effective Length | 233 mm | 223.6 mm | 230 mm | 223.6 mm | 230 mm |
| Overhang | 18.6 mm | 15 mm | 18.61 mm | 15 mm | |
| Tracking Error Angle | Less than 3 degrees | +/- 1.5° | Less than 3 degrees | ||
| VTA Adjustment Range | 0-6 mm | 2~4 mm | 0-6 mm | ||
| Applicable Cartridge Weight | 3.5~8.g (including headshell is 13~18g) | 3.5~8.g (including headshell is 13~18g) | 3.5~8.5g (including headshell is 13~20g) | 7.2 – 11.2 g (incl. Headshell) | 17 - 25g (including headshell) |
| Anti-Skating Range | 0 – 3g | 0 – 3g | 0 – 3g | 0 – 4g | 0 – 3g |
| Terminals | 1x PHONO out (gold-plated) | 1x PHONO / LINE out (gold-plated) 1x USB type B (PCM 48 kHz / 16-bit; Windows & macOS support) |
1x PHONO out (gold-plated) 1x GND earth terminal |
1x PHONO / LINE out (gold-plated) | 1x PHONO out (gold-plated) 1x GND earth terminal |
| General | |||||
| Power supply | DC 12V, 500mA | DC 12V, 500mA | AC 115/230 V, 60/50 Hz (EU/US) AC 100 V, 50/60 Hz (JP) |
12 V 1A DC | AC 100/240V, 50/60 Hz |
| Power Consumption | 6W | 6W | 9W | 12W | 3W |
| Dimensions (W)x(D)x(H) | 420 x 340 x 120 mm (incl. dust cover) |
450 x 352 x 138.7 mm (incl. dust cover) |
458 x 368.3 x 162.4 mm | 420 x 356 x 148 mm | 460 x 367.3 x 172.6 mm |
| Weight | 4.54 kg | 6.5 kg | Approx. 13 kg | 8.2 kg | 10.35 kg |
| Included Accessories | Turntable platter, dust cover, 2x dustcover hinges, balance counter weight, PHONO RCA Cable, DC power supply with international plugs, felt mat, instruction manual, Ortofon OM10 cartridge, headshell | Turntable platter, dust cover, 2x dustcover hinges, balance counter weight, PHONO RCA cable, DC power supply with international plugs, felt mat, instruction manual, Ortofon 2M Red cartridge, headshell | Turntable platter, dust cover, 2x dustcover hinges, balance counter weight, PHONO RCA cable with earth lead, AC power supply cord, rubber mat, instruction manual, Ortofon 2M Red cartridge & headshell | Acrylic turntable platter, dust cover, 2x hinges, felt mat, international power supply (UK/EU/US), RCA cable, headshell with Ortofon 2M Red (pre-installed), 7" aluminium adapter, allen key, USB-cable, instruction manual & counterweight | Turntable platter, dust cover, 2x hinge, rubber mat, power supply cable, RCA cable with grounding connection (gold-plated), Headshell with Ortofon 2M Blue (pre-installed), operation manual & counterweight |
| Price | |||||
| € | 359.99 | 529.99 | 799.99 | 999.99 | 1,299.99 |
